Honeywell DR4500A User Manual

Parts List
Exploded Views
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 227
April 2017
Table 10-3 Basic recorder parts without options
Key
Part Number
Description
Recommended
Spare Parts per
Quantity
per Unit
10
100
1
30754982-502
Main Transformer
1
3
1
2
51309355-501
Main PCB
1
5
1
3
(K)30756141-003
Input PCB (input 1 or 2)
1/3
4
See Note 2
3-position connector**
2
5
See Note 2
2-position connector**
1
6
(K)30755980-005
Fuse (Wilkman 19374-041K 500 ohm or equal)**
1
7
30754924-502
51452182-502
Case
Case NEMA 4
1
PARTS NOT SHOWN
See Note 2
Card guides for Input PCBs**
2
51197612-502
Ferrite Filter - Package of 2 (CE Mark)
1
51197755-001
Capacitor Kit (.01mfd) - 12 per kit (CE Mark)
30755232-502
0-10 Vdc Input Divider (input PCBs)
*
30756461-002
250 ohm Resistor Assembly
*
(K)30755065-501
(K)30755065-502
(K)30755065-503
Mounting Kit (standard)
Mounting Kit (Heavy Duty)
Mounting Kit (NEMA4X)
1
(K)30755134-002
Gray Universal Filler Plate Kit
*
(K)30755011-001
Filler Panel Kit (for replacing Servoline recorder)
*
(K)30757205-008
Kit to Upgrade/Add Totalization to Inputs #1 and #2 for Classic Recorder
*
51197657-502
Panel Mounting Gasket Kit
1
NOTE 2: These parts are included with applicable PCB kits, as required.
* As required
** These parts are also included in the miscellaneous hardware kit 30755980-003
