Setpoint Ramp/Soak Programming and Operation - Setpoint Program Segments Set Up Group
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 165
April 2017
6.7 Setpoint Program Segments Set Up Group
Introduction
You can configure up to 36 ramp and soak segments.
Setpoint program segments group prompts
Table 6-5 lists all the function prompts in the Setpoint Program Segments setup group and their definitions.
Table 6-5 Setpoint program segments group definitions
Upper Display
Range of Setting or Selection
A ramp segment is the time it takes to change the
setpoint to the next setpoint value in the program.
Ramps are odd number segments. Segment #1 will
be the initial ramp time.
This selection of time or rate is made at prompt
“RAMPUNIT”.
ATTENTION: Entering “0” implies an immediate step
change in setpoint to the next soak.
Within the setpoint high and low
range limits in engineering units
The soak segment's setpoint value
The soak segment’s duration.
