Setpoint Ramp/Soak Programming and Operation - Setpoint Program Profiles Set Up Group
164 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
Setpoint program profiles worksheet
Use this worksheet to keep a record of your setpoint program profile settings.
Prompt
Description
Range
Your selection
PROFILES
Settings for profiles
NA
NA
PR1 STRT
Start Segment for Program 1
RAMP1 to RAMP35
PR1 END
End Segment for Program 1
SOAK2 to SOAK36
PR2 STRT
Start Segment for Program 2
RAMP1 to RAMP35
PR2 END
End Segment for Program 2
SOAK2 to SOAK36
PR3 STRT
Start Segment for Program 3
RAMP1 to RAMP35
PR3 END
End Segment for Program 3
SOAK2 to SOAK36
PR4 STRT
Start Segment for Program 4
RAMP1 to RAMP35
PR4 END
End Segment for Program 4
SOAK2 to SOAK36
PR5 STRT
Start Segment for Program 5
RAMP1 to RAMP35
PR5 END
End Segment for Program 5
SOAK2 to SOAK36
PR6 STRT
Start Segment for Program 6
RAMP1 to RAMP35
PR6 END
End Segment for Program 6
SOAK2 to SOAK36
RAMPUNIT
Ramp Type
TIME
EU/MIN
EU/HR
SYNC 1+2
Synchronizes Profile for Control Loops
1 and 2
ENABLE
DISABL
