Configuration
Alarms Set Up Group
Release M DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual 73
April 2017
Function prompts
Table 3-12 lists all the function prompts in the Alarms Set Up group.
Table 3-12 Alarms group function prompts
Function Prompt
Lower Display
Function Name
Selections or Range of Setting
Upper Display
Factory
Setting
AxS1 VAL
Alarm 1, Setpoint 1 Value
Value in engineering units
90
AxS2 VAL
Alarm 1, Setpoint 2 Value
Value in engineering units
95
AxS1TYPE
Alarm 1, Setpoint 1 Type
NONE
IN 1 (Input 1)
IN 2 (Input 2)
RH (Relative Humidity)
PV (Process Variable Loop 1)
DEV (Loop 1 Deviation)
OUT (Loop 1 Output)
DEV2 (Loop 2 Deviation)
OUT2 (Loop 2 Output)
EVENT (SP Programming-Segment Event)
TOTAL 1 (Totalizer to Alarm On)
TOTAL 2 (Totalizer to Alarm On)
IN 1
AxS2TYPE
Alarm 1, Setpoint 2 Type
Same as A1S1TYPE
IN 1
AxS1 H L
Alarm 1, Setpoint 1 State
LO (Low Alarm)
H I (High Alarm)
LO
AxS1SCAL
Alarm 1, Setpoint 1 Scaling
Multiplier for Totalizer
Selection
1 10000
10 100000
100 1E6
1000
1
AxS2 H L
Alarm 1, Setpoint 2 State
LO
H I
HI
AxS2SCAL
Alarm 1, Setpoint 2 Scaling
Multiplier for Totalizer
Selection
1
10
100
1000
10000
100000
1E6
1
ALx HYST
Alarm Hysteresis
0.0 to 100.0 % of Input Span as appropriate
0.1
Repeat this procedure for ALARM 2, ALARM 3, ALARM 4, ALARM 5, ALARM 6.
