3.9 Totalizer Set Up Group
Introduction
The functions listed in this group deal with the calculation and display of the total flow volume as
measured by input 1 (total 1) or input 2 (total 2). The displayed value is 8 digits with a configurable scale
factor.
Function prompts
Table 3-6 lists all the function prompts in the “TOTAL 1” Set Up group. Repeat the process for input 2.
 Press the SET UP key until TOTAL 2 appears in the display.
Table 3-6 Totalizer group function prompts
Function Prompt
Lower Display
Function Name
Selections or Range of Setting
Upper Display
Factory
Setting
Actual Current
Totalized Value
View Current Totalized
Value
Current Scale Factor
Example: E1 GPM
E0 GAL
RSET TOT
Reset Totalizer to Zero
(RSETABLE must be set to
“LOCAL”)
NO
YES
NO
TOTAL 1
Totalizer 1
DISABL
INPUT1
INPUT2
DISABL
TOTAL EU
Total Engineering Units
0 to 9
A to Z
+
–
/
(blank)
GAL
RATE
Rate of Integration
SECOND
MINUTE
HOUR
DAY
M/DAY (Millions of Units per Day)
SECOND
SCALER
Totalizer Scale Factor
1 10000
10 100000
100 1E6 (1,000,000)
1000
1
RSETABLE
Totalizer Reset
NO
LOCAL
EXTSW1*
EXTSW2*
*Total will be set to “0” on closure of the
assigned external switch.
NO
INHIBIT
Totalizer Inhibit
NONE
S1 OPEN
S1 CLOSE
S2 OPEN
S2 CLOSE
NONE
Repeat this procedure for INPUT 2.
