Installation - Mounting Methods
26 DR4500A Classic Series Circular Chart Recorder With or Without Control Product Manual Release M
April 2017
181.36
7.14
163.32
6.430
18.03
0.710
196.22
7.725
369.6
14.550
Hole Pattern
Reference:
millimeters
inches
21409
NOTE:
These screws must be supplied by
user; all other mounting hardware
is supplied with recorder.
Support
hook
Figure 2-10 Mounting flush on a surface (of panel or wall)
