5 Power-On Commissioning
5.1 Preparations and WebUI Login
Prerequisites

Supported operating system: Windows 7 and later versions

It is recommended that the screen resolution be 1366 x 768 or higher.

Browser: Chrome, Firefox, Internet Explorer 11 or later
Procedure
Step 1 Connect a network cable between the PC network port and the WAN1 port (protected by a
security mechanism) on the ECC800-Pro.
Table 5-1 Default IP addresses for the WAN and LAN ports on the ECC800-Pro
Port
Default IP Address
WAN1
192.168.8.10
WAN2
192.168.0.10
192.168.248.10 (FusionModule800)
LAN1 and LAN2
192.168.248.10
