parameters are consistent with the parameters of the independent deployment
AI_DI unit.
----End
8.1.6.19 How to Set and Add a UIM20A Expansion Module (over
Modbus-TCP)?
Prerequisites
Connect one end of a network cable to the POE port on the UIM20A expansion module and
the other end to the LAN port on the ECC800-Pro or the POE port on the smart ETH gateway.
Cascading of user interface modules is not supported.
Context
The UIM20A expansion module supports self-discovery and does not need to set parameters.
Procedure
Step 1 Set the running parameters and control parameters for the UIM20A expansion module on the
WebUI.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose Monitoring > System > UIM Group > UIMn.
3. On the Running Parameters tab page, set UIM20A expansion module running
parameters.
4. On the Controls tab page, set the UIM20A expansion module control parameters.
----End
8.1.6.20 How to Set and Add the Multi-functional Sensor?
If a multi-functional sensor is installed, perform the following steps to configure it.
Prerequisites
One end of the straight-through cable has been connected to the POE port on the
multi-functional sensor, and the other end has been connected to the POE port on the ETH
converter.
Procedure
Step 1 Set multi-functional sensor parameters.
On the WebUI, choose Monitoring > Aisle > Multi-Func Sensor Group > Multi-Func
Sensor1 > Running Parameters, ensure that Smoke enable and Temp enable are set to
Enable, set High temperature alarm threshold and other parameters as required, and then
click Submit.
