ECC800 Data Center Controller
User Manual (for ECC800-Pro)
6 Feature Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
195
Figure 6-56 Links for a single smart cooling product
Table 6-42 Specifications of the links for a single smart cooling product
Item
Specifications
1
Smart cooling product appearance
2
Alarm (tap to view specific alarms)
3
Internal fan
4
Condensate pipe (yellow: high temperature)
5
Air inlet temperature of the smart cooling product
6
Refrigerant status
7
Air outlet temperature of the smart cooling product
----End
6.12.4 Setting the Temperature Map
If the temperature map function is configured, follow the instructions provided in this section
to commission it.
Prerequisites
1. Cables to the NTC and T/H sensors have been connected.
