3.2.17 PAD
The pad allows the wireless access from the data center management system. You can monitor
the equipment in the data center and environmental parameters in real time over the APP.
Figure 3-34 PAD
Table 3-60 Pad structural specifications
Item
Specification
Dimensions (L x W x
H)
243 mm x 164 mm x 7.8 mm
Weight
About 460 g
Table 3-61 PAD technical specifications
Item
Specifications
Touchscreen
10.1-inch, 1920 x 1200 resolution, IPS screen, and multi-touch
Storage

Machine: 32 GB

Memory: 3 GB

LPDDR3 extension card: microSD, a maximum of 256 GB
(non-standard configuration)
Button/Port

Touch button + power switch and volume button

3.5 mm stereo headphones port

Micro SD card port

MicroUSB port
Camera

Rear camera: 8-megapixel, F2.0 aperture, automatic focus

Front camera: 2-megapixel, F2.4 aperture, fixed focus
