Huawei ECC800 - How to Set and Add a PMAC615 AC Meter

ECC800 Data Center Controller
User Manual (for ECC800-Pro)
8 FAQ
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
238
Step 2 Add an ATS.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Add an ATS.
Table 8-10 Adding an ATS
Path
Parameter
Name
Setting
Choose System
Settings >
Device
Management
and click Add
Device. The
parameters for
adding devices
are displayed.
Device attribute
Select ATS from the drop-down list box.
Device Type
Select ATS from the drop-down list box.
Connect To
Select ECC800 from the drop-down list box.
Communications
Port
Select COM1 from the drop-down list box.
NOTE
The setting example indicates that the ATS connects to the
COM1 port on the ECC800-Pro. If the ATS connects to
another port, enter the number of the connected port.
Device Address
In this example, Device Address is set to 1. During
actual configuration, set the device address for the
ATS based on the actual situation.
3. Click Test Connect to check whether the ATS connects to the ECC800-Pro properly.
− If the ATS connects to the ECC800-Pro properly, click Confirm. The connected
devices are displayed in the Number of connected devices list.
− If the ATS does not connect to the ECC800-Pro properly, check whether the cable
between the ATS and the ECC800-Pro is connected properly, whether the ATS and
ECC800-Pro are running properly, and whether the input parameters are consistent
with the ATS parameters.
----End
8.1.6.10 How to Set and Add a PMAC615 AC Meter?
Prerequisites
One end of the straight-through cable has been connected to the RS485 port on the PMAC615
AC meter, and the other end has been connected to the COM port on the ECC800-Pro.
Context
The model of the single-phase AC meter for the lighting control box is PMAC615.
Procedure
Step 1 Set the PMAC615 communications address.
