Huawei ECC800 - Infrared Remote Control Module

ECC800 Data Center Controller
User Manual (for ECC800-Pro)
3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
69
Item
Temperature
Humidity
Extended
temperature
collection port
Provides two RJ45 ports to connect to six NTC temperature sensors,
each RJ45 port connecting to three NTC temperature sensors.
Signal port
RS485
Power supply
5–16 V DC (typical value 12 V DC)
Power consumption
< 280 mW
Storage
environment
–40°C to +70°C
Weight
About 85 g
3.2.19 Infrared Remote Control Module
Figure 3-43 Infrared remote control module
Table 3-70 Technical specifications of the infrared remote control module
Item
Specifications
Number of supported remote
control commands
≤ 4
Communication
Interworks with the monitoring system over Modbus-RTU
to implement remote control.
The baud rate can be 9600 bit/s.
Infrared emission distance
≤ 10 m
Power supply
9–16 V DC
Power
≤ 350 mA
