ECC800 Data Center Controller
User Manual (for ECC800-Pro)
8 FAQ
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
232
Path
Parameter
Name
Setting
Settings >
Device
Management
and click Add
Device. The
parameters for
adding devices
are displayed.
Device Type
Select PDU8000 from the drop-down list box.
Connect To
Select ECC800 from the drop-down list box.
Communications
Port
Select COM1 from the drop-down list box.
NOTE
The setting example indicates that the PDU8000 is
connected to the COM1 port on the ECC800-Pro. If the
PDU8000 is connected to another port, enter the number
of the connected port.
Device Address
In this example, Device Address is set to 1. During
actual configuration, set the device address for the
PDU8000 based on the actual situation.
3. Click Test Connect to check whether the PDU8000 connects to the ECC800-Pro
properly.
− If the PDU8000 connects to the ECC800-Pro properly, click Confirm. The
connected devices are displayed in the Number of connected devices list.
− If the PDU8000 does not connect to the ECC800-Pro properly, check whether the
cable between the PDU8000 and the ECC800-Pro is connected properly, whether
the PDU8000 and ECC800-Pro are running properly, and whether the input
parameters are consistent with the PDU8000 parameters.
----End
8.1.6.7 How Should I Set and Add a 5G DC Power Supply
(MTS9604B-N20B1)?
Prerequisites
One end of the straight-through cable has been connected to the COM1 port on the SMU11D
in the MTS9604B-N20B1 cabinet, and the other end has been connected to the COM port on
the ECC800-Pro collector or ETH converter.
Procedure
Step 1 Configure the northbound RS485 communication address.
