8.1.6.26 How to Set and Add the WLDS600 Water Sensor?
If a water sensor is installed, perform the following steps to configure it.
Prerequisites
One end of the straight-through cable has been connected to the RJ45 port on the WLDS600
water sensor, and the other end has been connected to the energized COM port on the
ECC800-Pro.
Procedure
Step 1 The default communications address 1 of the water sensor is used for connecting to the
ECC800-Pro.
Step 2 Log in to the ECC800-Pro WebUI as an administrator.
Step 3 Add the water sensor.
Table 8-25 Adding the water sensor
Path
Parameter
Name
Setting
Choose System
Settings >
Device
Management
and click Add
Device. The
parameters for
adding devices
are displayed.
Device attribute
Select Sensor from the drop-down list box.
Device type
Select Water Sensor from the drop-down list box.
Connect to
Select ECC800 from the drop-down list box.
Communications
port
Select COM1 from the drop-down list box.
NOTE
The setting example indicates that the water sensor is
connected to the COM1 port on the ECC800-Pro. If the
water sensor is connected to another port, enter the
number of the connected port.
Device address
In this example, Device address is set to 1. During
actual configuration, set the device address for the
water sensor based on the actual situation.
Step 4 Click Test Connect to check whether the water sensor connects to the ECC800-Pro properly.

If the water sensor connects to the ECC800-Pro properly, click Confirm. The connected
devices are displayed in the Number of connected devices list.

If the water sensor does not connect to the ECC800-Pro properly, check whether the
cable between the water sensor and the ECC800-Pro is connected properly, whether the
water sensor and ECC800-Pro are running properly, and whether the input parameters
are consistent with the water sensor parameters.
Step 5 Set water sensor parameters.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose Monitoring > System > Water Sensor > Running Parameters.
3. Set the parameters based on actual conditions, and click Submit.
