ECC800 Data Center Controller
User Manual (for ECC800-Pro)
8 FAQ
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
237
Table 8-9 Adding a PDU2000
Path
Parameter
Setting
Choose System
Settings >
Device
Management
and click Add
Device. The
parameters for
adding devices
are displayed.
Device attribute
Select PDU from the drop-down list box.
Device type
Select PDU2000-M (C) or PDU2000-M (H) from
the drop-down list box based on the actual device.
Connect to
Select ECC800 from the drop-down list box.
Communications
port
Select COM1 from the drop-down list box.
NOTE
The setting example indicates that the PDU2000 is
connected to the COM1 port on the ECC800-Pro. If the
PDU2000 is connected to another port, enter the number
of the connected port.
Device address
Enter the actual device address of the PDU2000.
3. Click Test Connect to check whether the PDU2000-M connects to the ECC800-Pro
properly.
− If the PDU2000 connects to the ECC800-Pro properly, click Confirm. The
connected devices are displayed in the Number of connected devices list.
− If the PDU2000 does not connect to the ECC800-Pro properly, check whether the
cable between the PDU2000 and the ECC800-Pro is connected properly, whether
the PDU2000 and ECC800-Pro are running properly, and whether the input
parameters are consistent with the PDU2000 parameters.
----End
8.1.6.9 How Do I Set and Add an ATS?
Prerequisites
One end of the straight-through cable has been connected to the COM port on the ATS, and
the other end has been connected to the COM port on the ECC800-Pro collector or ETH
converter.
Context
The ATS (ABB) model is OMD800.
Procedure
Step 1 Set the ATS device address. On the ATS display panel, press , choose Device
Configuration > Modbus and set the device address.

The ATS device address is 1 by default.

The initial password is 0001 for the ATS display panel.
