ECC800 Data Center Controller
User Manual (for ECC800-Pro)
8 FAQ
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
292
Figure 8-37 Turning on or off aisle lights
Follow-up Procedure
Set Set light mode is Automatic.
8.1.34 How Should I Opening Skylights Remotely over the
ECC800-Pro WebUI?
Context
You can open skylights over the ECC800-Pro WebUI in emergencies.
Procedure
Step 1 Log in to the ECC800-Pro WebUI as an administrator.
Step 2 Open skylights.
Table 8-48 Opening skylights
Path
Setting
Monitoring > Aisle > Skylight
Actuator Group > Skylight
Actuator n > Controls
Select Remote open scuttle and click Submit
Remotely opening the skylight may open the smart module skylight, and this may pose
security risks. Exercise caution when performing this operation.
----End
Example
The following figure shows how to open the skylights controlled by skylight actuator 1.
