3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
53
Item
Specifications
mA
Sound pressure
≥ 100±3 dB/30 cm
Continuous operating
time
≥ 45 min
3.2.12 (Optional) Smart U Space Manager
The smart U space manager is designed for IT asset management of the data center. The
system automatically detects the physical location of IT devices in the data center, collects IT
asset codes and the information about U space usage.
Figure 3-27 Smart U space manager
(1) Asset detection strip
(2) Asset label
(3) Main control box
Table 3-51 Technical specifications of the smart U space manager
Item
Specifications
Characteristic
Applicable to 42 U cabinets
Communications port
RS485, Modbus-RTU
Communication
Rate: 9600 bit/s
Communication format: one start bit, eight data bits, no
parity bit, one stop bit
Power input
12 V DC±5% (RJ45)
Rated current and power
consumption
250 mA
Data upload port
One RS485 route (two RJ45 ports)
Dimensions (mm)
Main control box: 71 mm x 70 mm x 25 mm
