ECC800 Data Center Controller
User Manual (for ECC800-Pro)
Copyright © Huawei Technologies Co., Ltd.
5.6 Commissioning the eLight
If an eLight is installed, perform the following steps to configure it.
Procedure
Step 1 Ensure that the device address of the eLight actuator is the default value 2.
Toggle switches 1 to 4 of the DIP switch specify the device address in binary mode. ON
indicates 1, and OFF indicates 0.
Table 5-5 Setting a device address
Step 2 Check the eLight function.
Table 5-6 Function check
Choose Maintenance > Configuration
Wizard > Linkage Test > eLight
Controller Commissioning and click Test.
The eLight is lit up in red, green, blue, and
white in sequence for 3 seconds
respectively, and then turns off.
Step 3 Set eLight parameters.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. In the Smart Module View, click Modify Device. Select an eLight actuator under
Devices, drag it to the access actuator to which you want to bind the eLight actuator, and
click Exit Edit Mode.
