6.4.4 Commissioning an Emergency Door Release Button
Procedure
Step 1 Check the function of an emergency door release button.
Table 6-20 Function check
Check Method
Normal Connection
Status
Follow-up Procedure
When the room door is
properly closed,
short-circuit the wiring
terminals NC and COM or
NO and COM on the
emergency door release
button.
The room door is opened
properly.
Remove the short-circuit
cable from the wiring
terminals NC and COM or
NO and COM on the
emergency door release
button.
----End
6.5 Video Management
6.5.1 Preparing Documentation
Before commissioning a camera, prepare the following documents in addition to this
document.
Table 6-21 Documentation for commissioning preparation
Component
Document
IPC6325-WD-VR
IPC6325-WD-VR Configuration Guide
VCN500/VCN510/VCN520
/VCN540
VCN500: VCN500 Product Documentation
VCN510/VCN520/VCN540:
VCN510&VCN520&VCN540 Product Documentation
6.5.2 Networking Scenarios
Smart ETH Gateway Networking Scenario

If there are multiple VCNs for multiple smart modules, you are advised to evenly
distribute the cameras to each VCN.

A maximum of four cameras can be connected in the smart ETH gateway networking
scenario.
