Huawei ECC800 - 3.2.20 Intelligent Battery Monitoring System

ECC800 Data Center Controller
User Manual (for ECC800-Pro)
3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
59
Figure 3-31 Electrode water sensor
Table 3-56 Electrode water sensor technical specifications
Item
Specification
Operating
temperature
–40°C to +80°C
Storage
temperature
–40°C to +80°C
Service life
10 years
3.2.15 WiFi Module
The WiFi module provides WiFi signals for equipment such as pads and mobile phones to
interact with the host computer.
Figure 3-32 WiFi module
Table 3-57 Technical specifications
Item
Specifications
Wireless standard
IEEE 802.11n, IEEE 802.11g, and IEEE 802.11b
Network
bandwidth

11n: up to 150 Mbps

11g: up to 54 Mbps

11b: up to 11 Mbps
Frequency band
2.4–2.4835 GHz
