ECC800 Data Center Controller
User Manual (for ECC800-Pro)
8 FAQ
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
234
Step 2 Add a 5G DC power supply.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Add a 5G DC power supply.
Table 8-7 Adding a 5G DC power supply
Path
Parameter
Setting
Choose System
Settings >
Device
Management
and click Add
Device. The
parameters for
adding devices
are displayed.
Device attribute
Select a DC Power Source from the drop-down list
box.
Device Type
Select MTS9604B_MTS9606B Power Supply
from the drop-down list box.
Connect To
Select ETH Converter from the drop-down list
box.
Communications
Port
Select COM1/COM2 from the drop-down list box.
NOTE
The setting example indicates that the 5G DC power
supply is connected to the COM1 port on the
ECC800-Pro. If the 5G DC power supply is connected to
another port, enter the number of the connected port.
Device Address
In this example, Device Address is set to 1. Set the
device address based on the actual situation.
3. Click Test Connect to check whether the 5G DC power supply is properly connected to
the ECC800-Pro.
− If the connection is normal, click Confirm. The connected devices are displayed in
the Number of connected devices list.
− If the connection is abnormal, check whether the device is properly connected to the
ECC800-Pro, whether both are running properly, and whether the parameter
settings are consistent with the device parameters.
----End
8.1.6.8 How to Set and Add a PDU2000?
Prerequisites
One end of the straight-through cable has been connected to the COM 1 or COM 2 port on the
PDU2000, and the other end has been connected to the COM port on the ECC800-Pro
collector, UIM20A expansion module, or ETH converter.
