3.2.9 Temperature Sensor
The temperature sensor (BOM number: 33010348) is used for the surface temperature
measure, industrial process control, measurement instrument, etc.
Figure 3-24 Temperature sensor
Table 3-47 Temperature sensor specifications
Item
Specifications
Measurement range
–20°C to +70°C
Measurement precision
±1°C (25°C)
Operating temperature
–10°C to +55°C
Operating voltage
10–16 V DC
Storage temperature
–40°C to +70°C
3.2.10 Cabinet Temperature Sensor
Figure 3-25 Cabinet temperature sensor
