ECC800 Data Center Controller
User Manual (for ECC800-Pro)
Copyright © Huawei Technologies Co., Ltd.
Table 8-22 Function check
Simulate a smoky
environment under
the smoke sensor.
Smoke sensor status(AI/DI_1)
is displayed on the active alarm
page of the app or WebUI.
If Smoke sensor type is Smoke
Sensor, power off and reset the
smoke sensor to clear the alarm.
----End
8.1.6.24 How Should I Set and Add the Smoke Sensor (Connected to the
AI/DI Port on the UIM20A expansion module)?
If a smoke sensor is installed, perform the following steps to configure it.
Prerequisites
One end of the network cable has been stripped, core wires 1, 5, and 8 have been
short-circuited, core wires 6 and 7 have been connected to the cable delivered with the smoke
sensor, and the other end of the network cable has been connected to the AI/DI port on the
UIM20A expansion module.
Context
If the sensor is prefabricated, only check its settings.
The actual value prevails. Only the method of the parameter settings is described.
Procedure
Step 1 Set smoke sensor parameters.
In this example, the smoke sensor is connected to the AI/DI_1 port on the UIM20A expansion module.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose Monitoring > System > UIM Group> UIM n > Running Parameters.
3. In AI/DI_1 Port Settings area, set AI/DI_1 sensor to Enable, click Submit.
4. Set AI/DI_1 sensor type to Smoke sensor, click Submit.
Step 2 Check the monitoring functions of smoke sensor.
Table 8-23 Function check
Simulate a smoky
environment under
the smoke sensor.
Smoke sensor status(AI/DI_1)
is displayed on the active alarm
page of the app or WebUI.
If Smoke sensor type is Smoke
Sensor, power off and reset the
smoke sensor to clear the alarm.
----End
