6. Set Leak sensor to Enable and click Submit.
7. Confirm that Leak sensor type is automatically identified as Leak sensor(Electroc).
8. Click Unhide All Advanced Signals, then click Power Supply Parameters. Ensure that
II power supply enable(AIDI_3/COM2/AIDI_5) is Yes.
Step 2 Check functions of water sensors.
Table 8-27 Function check
Immerse the two
contacts of the
electrode water
sensor in water.
Leak DI alarm is generated on
the active alarm screen of the
app or on the WebUI.
Wipe dry the two contacts of the
water sensor. The alarm
disappears automatically.
----End
8.1.6.28 How to Set and Add the Temperature Sensor (Connected to the
AI/DI Port on the ECC800-Pro)?
If a temperature sensor is installed, perform the following steps to configure it.
Prerequisites
One end of the straight-through cable has been connected to the RJ45 port on the temperature
sensor, and the other end has been connected to the AI/DI port on the ECC800-Pro.
Context
If the sensor is prefabricated, only check its settings.
The actual value prevails. Only the method of the parameter settings is described.
If multiple temperature sensors are connected, commission them one by one.
Procedure
Step 1 Set temperature sensor parameters.
In this example, the temperature sensor is connected to the AI/DI_2 port on the ECC800-Pro.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Choose System Settings > Signal Name Modify. The Batch Signal Configuration
page is displayed.
3. Set Device type to ECC800, set Device name to ECC800, and click OK.
4. On the query result tab page, set the new signal name of AI/DI_2 to Temperature and
click Submit.
5. Choose Monitoring > System > ECC800 > Running Parameters > AI/DI_2 Port
Settings.
6. Set Temperature sensor to Enable and click Submit.
