ECC800 Data Center Controller
User Manual (for ECC800-Pro)
Copyright © Huawei Technologies Co., Ltd.
6.11 Power Management
6.11.1 Configuring Power Management Parameters
Prerequisites
Power distribution devices (such as the integrated UPS, integrated PDU and precision
PDC) are successfully connected to the ECC800-Pro.
The smart module plan view has been created, and the device positions in the plan view
are consistent with actual positions.
Context
IT cabinets, network cabinets, and smart cooling products support power management. The
ECC800-Pro connected to an IT cabinet is used as an example in this section.
Procedure
Step 1 Log in to the ECC800-Pro WebUI as an administrator.
Step 2 Choose Home > Plan View > Modify Device and click Apply Power Distribution
Standard Configuration to use the default configuration to configure electricity for devices
in the smart module. The following scenarios support the function of applying default
electricity configuration:
N+1 scenario: The system has only one power distribution cabinet and is working in
single-power supply mode.
2N non-isolation scenario: The system has only one power distribution cabinet and is
working in dual-power supply mode.
2N isolation scenario: The system has two power distribution cabinets and is working in
single-power supply mode.
For details about the power distribution solution, refer to the power distribution wiring diagram supplied
with the product.
Step 3 Double-click a network cabinet to access the Basic Configuration page.
Step 4 Check whether the branch information configured on the Power distribution standard is
consistent with the actual situation. Set power configuration parameters based on site
requirements, such as the Device Name, Cabinet height, Power system, Number of power
supplies, and Rated cabinet power.
The settings in the following table are used as examples to describe the basic configuration.
Table 6-39 Basic configuration
Set based on the actual device
name.
U space quantity of the cabinet.
