Huawei ECC800 - Water Sensor; WLDS600 Water Sensor

ECC800 Data Center Controller
User Manual (for ECC800-Pro)
3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
55
Figure 3-28 eLight actuator
Table 3-53 eLight actuator technical specifications
Item
Specifications
Dimensions (L x W x H)
112 mm x 76 mm x 35 mm
Power input
DC input: terminal, with the input voltage of 24 V DC
Power output
AC output: terminal, with the output voltage of 120 V AC
RS485 port (RJ45)
Two RS485 ports, support cascading
Installation
Install on a guide rail
Operating temperature
4°C–40°C
Ambient humidity
5%–95% RH (non-condensing)
3.2.14 Water Sensor
A water sensor detects water on the floor in real time and generates an alarm when water is
detected.
3.2.14.1 WLDS600 Water Sensor
The WLDS600 water sensor consists of a water detection cable, a water detector with the
BOM number of 33010556, an extension line, and a conversion cable.
