ECC800 Data Center Controller
User Manual (for ECC800-Pro)
3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
56
Figure 3-29 WLDS600 water sensor
(1) Tie line
(2) Water leakage location cable
(3) End cap A (B)
(4) Extension line
(5) Water leakage locator

Two types (A and B) of end caps are delivered. The site may support only one type.

Connect either end cap to the cable. After the cable is connected and the water leakage locator is
powered on and initialized, if the buzzer keeps buzzing and the alarm location is a stable value that
is greater than the total length of the water leakage location cable, replace the end cap with the other
end cap.
Table 3-54 WLDS600 water sensor specifications
Item
Specification
Dimensions (L
x W x H)
70 mm x 58 mm x 86 mm±1
Power supply
9–16 V DC or 9–16 V AC
