Huawei ECC800 - Commissioning the Elight (for Fusionmodule800)

ECC800 Data Center Controller
User Manual (for ECC800-Pro)
5 Power-On Commissioning
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
107
Item
Alarm Severity
Selection
Description
Critical, Major, Minor
strip light preferentially turns on with a
light corresponding to the high-severity
alarm. After the high-severity alarm is
cleared, the eLight strip light turns on
with a light corresponding to the
low-severity alarm.
NOTE

Critical: red light

Major: orange light

Minor: yellow light

Warning: white light
Critical, Major,
Minor, Warning
None
The eLight strip light is steady blue
(atmosphere light).
NOTE
After you set the alarm severity, the eLight indicator is off if no alarm is generated.
5.7 Commissioning the eLight (for FusionModule800)
When the system type is FusionModule800 an eLight is installed, perform the following steps
to configure it.
Procedure
Step 1 Ensure that the device address of the eLight actuator is the default value 2.
Toggle switches 1 to 4 of the DIP switch specify the device address in binary mode. ON
indicates 1, and OFF indicates 0.
Table 5-9 Setting a device address
Address
Toggle
Switch 1
Toggle
Switch 2
Toggle
Switch 3
Toggle
Switch 4
1
ON
OFF
OFF
OFF
2
OFF
ON
OFF
OFF
3
ON
ON
OFF
OFF
4
OFF
OFF
ON
OFF
Step 2 Add an eLight.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Add an eLight.
