Check Method
Normal Connection Status
Method 1: Attempt to open the door using
the configured authentication mode.
Method 2: On the WebUI, choose
Monitoring > Aisle > Access Actuator
Group > Access Actuator n, and click
Controls to open the door remotely.
For method 1: The aisle door is opened
successfully.
For method 2: After you choose Query >
Access Event on the WebUI, you can view
the type of this access control event.
Step 4 Check the functions of the cabinet electric lock.
Table 6-14 Function check
Check Method
Normal Connection Status
Method 1: Ensure that the cabinet door is
closed, and attempt to open the door with an
IC card.
Method 2: On the WebUI, choose
Monitoring > Cabinet > IT Cabinet n >
E-LOCK n, and click Controls to open the
door remotely.
For method 1: Swipe an authorized IC card,
press the lower part of the cabinet electronic
lock when the green indicator blinks, and
open the cabinet electronic lock.
For method 2: After the cabinet electrical
lock is remotely opened, press the lower
part of the cabinet electronic lock after the
green indicator blinks, and open the cabinet
electronic lock. Choose Query > Access
Event on the WebUI, you can view the type
of this access control event.
----End
6.4.3 Commissioning the Exit Button, Skylight Button,
Atmosphere Light, Emergency Button, and Magnetic Lock
Procedure
Step 1 Check functions of the exit button.
Table 6-15 Function commissioning
Check Method
Normal Connection Status
Attempt to open the door by pressing the
exit button when the aisle door is closed.
The aisle door is opened successfully.
Step 2 Check functions of the skylight button.
