Huawei ECC800 - Commissioning the PDU2000 (for Fusionmodule800)

ECC800 Data Center Controller
User Manual (for ECC800-Pro)
5 Power-On Commissioning
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
109
Item
Alarm Severity
Selection
Description

Critical: red light

Major: orange light

Minor: yellow light

Warning: white light
None
The eLight strip light is steady blue
(atmosphere light).
NOTE
After you set the alarm severity, the eLight indicator is off if no alarm is generated.
Step 4 If there are multiple eLights, repeat Step 1–Step 3.
----End
5.8 Commissioning the PDU2000 (for FusionModule800)
When the system type is FusionModule800 and a PDU2000 is installed, perform the
following steps to configure it.
Prerequisites
Connect one end of the straight-through cable to the COM port on the PDU2000 and the other
end to the COM port on the ETH converter.
Context
Table 5-12 PDU2000 basic Information
Vendor
Name
Displayed on
the WebUI
Eleventh and Twelfth
Characters in Device
Barcode
a
Clever
PDU2000-M(C)
FT
Haipengxin
PDU2000-M(H)
6B
a: The barcode starts with 21 and is attached to the device.
Procedure
Step 1 Set the PDU2000 monitoring parameters.

Set the PDU2000-M (C) monitoring parameters.
The display of a single-phase module is used as an example.
