ECC800 Data Center Controller
User Manual (for ECC800-Pro)
3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
54
Item
Specifications
Detection strip: 1867 mm x 18 mm x 6.5 mm (H x W x
D)
Weight
≤ 0.2 kg (main control box), ≤ 0.35 kg (asset detection
strip)
Installation mode
Magnet-based installation
3.2.13 eLight Actuator
The eLight actuator has the function of associating alarms, access authorization status, and
atmospheres.
Table 3-52 eLight functions
Light of the
eLight Strip Light
eLight Strip Light
Lighting
Specifications
Cause
Red light
Steady on
The smart module raises a critical alarm.
Blinking for 3 seconds
Access authorization fails and the aisle
door cannot be opened.
Blinking
The eLight fails to communicate with the
ECC800-Pro.
Orange light
Steady on
The smart module raises a major alarm.
Yellow light
Steady on
The smart module raises a minor alarm.
Gray light
Steady on
The smart module raises a warning.
Green light
Blinking for 3 seconds
Access authorization succeeds and the
door can be opened.
Blue light
Steady on
Associated alarm severity is set to None.
Other color light
Steady on or blinking
The device is abnormal or cables are
incorrectly connected to terminals R, G,
and B.
