ECC800 Data Center Controller
User Manual (for ECC800-Pro)
Copyright © Huawei Technologies Co., Ltd.
8.1.6.4 How to Set and Add a PDU8000 or integrated PDU (over
Modbus-TCP)?
Prerequisites
One end of the straight-through cable has been connected to the FE port on the PDU8000 or
integrated PDU, and the other end has been connected to the PoE port on the smart ETH
gateway.
Context
The method of connecting the PDU8000 to the ECC800-Pro is the same as that for the
integrated PDU. Connecting the integrated PDU to the ECC800-Pro by following the
instructions in this section.
Procedure
Step 1 Set the PDU8000 monitoring parameters.
1. Enter the PDU8000 home screen, tap System Info.
2. Choose System Info > Settings, enter the user name admin and password 000001, and
tap .
3. Tap Communication to set IP address assign to Automatic(DHCP) on the displayed
communication settings screen and the PDU8000 is discovered by ECC800-Pro
automatically and is connected to the ECC800-Pro.
----End
8.1.6.5 How Do I Set and Add a C20 Lithium Battery (Modbus-TCP)?
Prerequisites
Connect one end of the straight-through cable to the FE port on the C20 lithium battery and
the other end to the PoE port on the smart ETH gateway.
Procedure
Step 1 Set C20 lithium battery monitoring parameters.
1. On the home screen of the C20 lithium battery, tap System Info.
2. Choose System Info > Settings, enter the user name admin and password 000001, and
tap .
3. Tap Communication to set IP address assign to Automatic(DHCP) on the displayed
communication settings screen and the C20 lithium battery is discovered by ECC800-Pro
automatically and is connected to the ECC800-Pro.
----End
