ECC800 Data Center Controller
User Manual (for ECC800-Pro)
8 FAQ
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
261
7. Confirm that Temperature sensor type is automatically identified as NTC. Ensure that
Temperature power supply is Yes.
8. Click Unhide All Advanced Signals, then click Power Supply Parameters. Ensure that
I power supply enable(AIDI_2/COM1/AIDI_4/COM3) is Enable.
Step 2 Check the monitoring functions of the temperature sensor.
Table 8-28 Function check
Check Method
Normal Connection Status
View the operating information
about the temperature sensor on
the WebUI.
You can view the current cabinet temperature.
----End
8.1.6.29 How to Set and Add the Temperature Sensor (Connected to the
NTC Port on the Rack Environment Unit)?
If a temperature sensor is installed, perform the following steps to configure it.
Prerequisites
One end of the straight-through cable has been connected to the RJ45 port on the temperature
sensor, and the other end has been connected to the NTC port on the rack environment unit.
Procedure
Step 1 The temperature sensor supports self-discovery and does not need to set parameters.
Step 2 Check the monitoring functions of the temperature sensor.
Table 8-29 Function check
Check Method
Normal Connection Status
Path: Monitoring > Cabinet >
IT Cabinet n > Cabinet
Collector n
You can view the current cabinet temperature.
----End
8.1.6.30 How Should I Commission a Temperature Sensor (Connected to
the NTC Port on the T/H Sensor)?
If a temperature sensor is installed, perform the following steps to configure it.
