Huawei ECC800 - ETH Converter

ECC800 Data Center Controller
User Manual (for ECC800-Pro)
3 Device Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
60
Item
Specifications
Wireless
transmission
power
20 dBm (MAX EIRP)
Supported
operating system
Windows 2000/XP/Vista/Linux/Win 7
Port
USB 2.0 Hi-Speed connector
Voltage range
5.0 V DC±5%
Operating
temperature
–20°C to +70°C
Storage
temperature
–40°C to +90°C
Relative humidity
10%–90% RH (non-condensing)
Storage humidity
5%–90% RH (non-condensing)
Power
< 0.8 W
3.2.16 ETH Converter
The ETH converter is used to convert the Modbus–RTU protocol or CAN protocol to the
Modbus-MAC protocol for connecting to the POE bus.
Figure 3-33 ETH converter
(1) Status indicator
(2) BLINK button
(3) COM1 communications port
(4) COM2 communications port
(5) 48 V power port
(6) POE port
