ECC800 Data Center Controller
User Manual (for ECC800-Pro)
8 FAQ
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
286
Path
Parameter
Setting
Choose System
Settings >
Device
Management
and click Add
Device. The
parameters for
adding devices
are displayed.
Device attribute
Select the device attribute to be accessed from the
drop-down list box.
Device Type
Select the device type to be accessed from the
drop-down list box.
Connect To
Select ECC800 from the drop-down list box.
Communications
Port
Select COM1 from the drop-down list box.
NOTE
The setting example indicates that the device connects to
the COM1 port on the ECC800-Pro. If the device
connects to another port, enter the number of the
connected port.
Device Address
This section uses 1 as an example. In practice, set
this parameter to be the same as the
communications address for the device.
3. Click Test Connect to check whether the device connects to the ECC800-Pro properly.
− If the independent deployment AI_DI unit connects to the ECC800-Pro properly,
click Confirm. The connected devices are displayed in the Number of connected
devices list.
− If the connection is not proper, check that the cable is properly connected between
the device and the ECC800-Pro, that the device and ECC800-Pro are running
properly, and that the input parameters are consistent with the device parameters.
----End
Follow-up Procedure
Choose Home > Plan View on the ECC800-Pro WebUI, and drag the device to the
corresponding position in the Smart Module View pane based on the actual device layout.
8.1.29 How Should I Add Devices Accessed Through the
ECC800-Pro AI/DI Port to the ECC800-Pro WebUI
Prerequisites
This section uses the device connecting to the AI/DI_3 port on the ECC800-Pro as an
example.
