− After the PDU2000-M (C) is powered on, the LCM displays the initialization
screen.
Figure 5-10 PDU2000-M (C) initialization screen
− Press MENU to enter the device communications address screen.
Figure 5-11 PDU2000-M (C) communications settings
− Set address to 1 by pressing DOWN and UP.
− Press MENU to confirm the settings.
The parameter settings take effect only if you press MENU and then the PDU2000-M (C) buzzes and
restarts. If you do not press MENU, the PDU2000-M (C) buzzes and restarts automatically after 30s and
the settings are not saved.

Set the PDU2000-M (H) monitoring parameters.
The display of a single-phase module is used as an example.
− After the PDU2000-M (H) is powered on, press MENU. The LCM displays
.
− Press MENU again to access the device communications address screen.
