Parameter
Setting
Description
Cabinet width
600
The width of the cabinet.
Power
Distrib
ution
Param
eter
Setting
s
Power
system
Single-phase
Set single-phase or three-phase
based on the actual power supply.
Numb
er of
power
supplie
s
2
rPDU quantity.
Rated
cabinet
power
6.00
Set based on the actual rated
power of the cabinet.
rPDU-A01
PDU80001 > 1QF1(L1)
Select a power distribution device
and power distribution branch for
the rPDU numbered rPDU-A01 in
the cabinet.
rPDU-B01
PDU80001 > 2QF1(L1)
Select a power distribution device
and power distribution branch for
the rPDU numbered rPDU-B01 in
the cabinet.
Branch auto-fill
mode

Ascending order

Descending order

Ascending order: If the branch
for the first cabinet is
1QF1(L1), 2QF1(L1), the
branches for subsequent
cabinets are 1QF2(L2),
2QF2(L2), and the like.

Descending order: If the
branch for the first cabinet is
1QF10(L1), 2QF10(L1), the
branches for subsequent
cabinets are 1QF9(L3),
2QF9(L3), and the like.
