Figure 8-14 PDU2000-M (C) communications settings
− Set address to 1 by pressing DOWN and UP.
− Press MENU to confirm the settings.
The parameter settings take effect only if you press MENU and then the PDU2000-M (C) buzzes and
restarts. If you do not press MENU, the PDU2000-M (C) buzzes and restarts automatically after 30s and
the settings are not saved.
Set the PDU2000-M (H) monitoring parameters.
The display of a single-phase module is used as an example.
− After the PDU2000-M (H) is powered on, press MENU. The LCM displays
.
− Press MENU again to access the device communications address screen.
Figure 8-15 PDU2000-M (H) communications settings
− Press DOWN and UP to select the address to be set.
− Press MENU to confirm the settings.
If modification is successful, is displayed: If modification fails, is
displayed:
Step 2 Add a PDU2000.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Add a PDU2000.
