6. Remove the network cable from the PC to the POE port on the ETH gateway.
7. Use a network cable to connect the PC to the LAN1 port on the ECC800-Pro, and
reconnect the network cable from the smart ETH gateway to the LAN2 port on the
ECC800-Pro.
Step 2 Set the IP address for the IPC6325 camera.
1. Enter https://192.168.248.10 in the address box of the browser and press Enter to access
the WebUI login page. After login, choose System Settings > Video Management.
2. (Optional) Click Search.
The search timeout interval is 10s. If the search fails, a search failure message is displayed.
To avoid missing cameras, perform Search for multiple times.
3. On the found camera record, click and set the external IP address for the camera
based on the external IP address (PC IP address and camera external IP address should
be in the same network segment) allocated by the network administrator.
4. Click the link under Link to access and log in to the camera WebUI. Enter the preset
user name admin and the preset password HuaWei123, and click Log In.
Figure 6-12 Clicking the camera access link
5. Choose Settings > Network > TCP/IP, set Way to obtain IPv4 to Use the following
IP address and set an IP address to the planned IP address for the camera. The IP
address should be in the range of 192.168.248.50 to 192.168.248.199.
Step 3 On the ECC800-Pro WebUI, click Add under Video Information. In the New Video
Information dialog box that is displayed, enter camera/VCN information.
Name: Enter the camera/VCN name (for example, Camera1).
External IP: Enter the external IP address of the camera (the actual IP address planned
by the customer prevails).
Internal IP: Enter the internal IP address, that is, the IP address of the camera/VCN (for
example, 192.168.248.56).
