ECC800 Data Center Controller
User Manual (for ECC800-Pro)
6 Feature Description
Issue 06 (2020-04-22)
Copyright © Huawei Technologies Co., Ltd.
162
Table 6-30 Setting AC actuator parameters
Path
Operation
Monitoring > Aisle > AC Actuator
Group > AC Actuator > Running
Parameters
Set Route 1 Control Mode to Light, and
click Submit.
Set Route 2 Control Mode to PAD
Charging, and click Submit.
NOTE
If two AC actuators are configured, you only
need to set the Route 2 Control Mode for one
AC actuator.
Step 7 Check the functions of the AC actuator.
Table 6-31 Function check
Check Method
Normal Connection Status
Path: Monitoring > Aisle > AC Actuator Group > AC
Actuator
1. Choose Running Parameters, and set Set light
mode is Manual.
2. Choose Controls, select Light control, select ON,
and click Submit.
The light is on.
When the light is normal, set Set light mode to Automatic. Path: Monitoring > Aisle >
AC Actuator Group > AC Actuator, click Running Parameters.
Step 8 Set camera parameters.

If the camera is connected to the smart ETH gateway, you need to set camera parameters for
intelligent lighting linkage.

The camera checks whether there are people motions in the aisle and an infrared alarm is generated.
If so, the AC actuator turns on the lights.

If the IP address of the camera that is automatically connected is the same as the IP address of the
camera that is manually added, the information about the camera that is manually added is
overwritten.
1. Select the actual camera type and go to the camera web page. For details, see the section
about camera commissioning.
2. Choose Settings > Network > Platform Connection > Second Protocol Parameters.
On the ONVIF and GENETEC tab pages, set platform interconnection parameters.
