Step 2 Add the device to the ECC800-Pro WebUI.
1. Log in to the ECC800-Pro WebUI as an administrator.
2. Add the device.
Table 8-40 Parameter description for adding a device
Choose System
Settings >
Device
Management
and click Add
Device. The
parameters for
adding devices
are displayed.
Select the device attribute to be accessed from the
drop-down list box.
Select the device type to be accessed from the
drop-down list box.
Select the corresponding ETH converter from the
drop-down list box.
NOTE
Use the blinking function of the ETH converter to identify
the mapping between the device and the ETH converter.
This section uses 1 as an example. In practice, set
this parameter to be the same as the
communications address for the device.
3. Click Test Connect to check whether the device connects to the ECC800-Pro properly.
− If the independent deployment AI_DI unit connects to the ECC800-Pro properly,
click Confirm. The connected devices are displayed in the Number of connected
devices list.
− If the connection is not proper, check that the cable is properly connected between
the device and the ECC800-Pro, that the device and ECC800-Pro are running
properly, and that the input parameters are consistent with the device parameters.
4. Choose Monitoring > System > ETH Converter Group > ETH Converter n >
Running Parameters and set Device name to ETH Converter n_Device name.
----End
Follow-up Procedure
Choose Home > Plan View on the ECC800-Pro WebUI, and drag the device to the
corresponding position in the Smart Module View pane based on the actual device layout.
