(10) AI/DI_2 dry contact
(reserved port for linkage
control or third-party fire
extinguishing system dry
contacts)
(11) AI/DI_1 dry contact
(reserved port for exit
button)
(12) LOCK/GND/GATE/COM
door status or magnetic lock port
Specifications
Table 3-28 Access actuator technical specifications
Item
Specifications
Power input

DC input: Terminal, with input voltage of 36–60 V DC

POE input: One POE port that complies with IEEE802.3at.
POE port
FE communication, 10/100M communications rate
Wireless
communication
One wireless communication port that complies with IEEE802.15.4,
mutual backup with FE communication
AI/DI port
Two AI/DI ports, can connect to the fire alarm and exit button
DO/DI port

One 12 V DC power output that controls magnetic locks, terminal

One DI input port for connecting to the door status switch
RS485 serial
port expansion
Two RS485 ports (one route) with the default communications rate of
9600 bit/s, physical port cascading supported (reserved function)
Wiegand
interface
Two Wiegand interfaces, 12 V DC card reader operating power output;
two routes of card readers (non-fingerprint readers) can operate at the
same time.
BLINK button

Press the button for less than 1 second to start blinking.

Hold down the button for 1–5 seconds to search for a network and
start networking.

Hold down the button for more than 10 seconds to clear network
parameters.
Address DIP
switch
4-pin address DIP switch
E-label
Supported
Indicators
Table 3-29 Access actuator indicators
Indicator
Color
Name
Status
PWR
Green
Power input
status indicator

Steady on: The power input is normal.
