No. Description
4 One ETH management port
5 One USB port
6 One PNP button
NOTICE
● Holding down the button for more than 6s restores the factory settings and
resets the device.
● Pressing the button resets the device.
● Resetting the device will interrupt services. Exercise caution when using this
button.
7 Ground screw
NOTE
The screw needs to be used with a ground cable.
8 Power module slot 1
NOTE
Supported power module: 1000 W AC PoE power module (PAC1000S56-CB)
9 Power module slot 2
NOTE
Supported power module: 1000 W AC PoE power module (PAC1000S56-CB)
Item
lists technical specications of the S5735-S24P4X.
Table 4-8 Technical
specications
Specications
Specications
Memory (RAM) 1 GB
Flash Physical space: 512 MB. To view the actual available space,
run display version.
MTBF 59.88
MTTR 2
Availability > 0.99999
Service port
surge protection
Common mode: ±7 kV (The maximum voltage is ±10 kV,
and the device is not damaged.)
Power port surge
protection
● Dierential mode: ±6 kV; common mode: ±6 kV
iMaster NetEco
Device Installation and Commissioning Guide (Data
Center) 4 Connecting Monitoring Cables to Devices
Issue 02 (2021-05-12) Copyright © Huawei Technologies Co., Ltd. 78
