Cluster multicast MAC address : 0180-c200-000a(default)
Cluster auto-join : disabled
Handshake timer:10 sec
Handshake hold-time:60 sec
IP pool:10.0.0.1/8
Logging host:4.0.0.1
SNMP host:3.0.0.1
FTP server:2.0.0.1
SFTP server:2.0.0.2
cluster-member ftp-timeout: 300 sec(default)
Cluster SNMP NAT capability : enabled
Cluster FTP NAT capability : disabled
There are 4 member(s) in the cluster, and 0 of them are down.
Step 10 Disable SNMP NAT on the administrator switch.
[HUAWEI_0.Administrator-1] cluster
[HUAWEI_0.Administrator-1-cluster] undo cluster-snmp-nat enable
Step 11 Configure the routes of member switches to ensure that reachable routes exist between member
switches and the SNMP host.
# Configure member switch 1.
[HUAWEI_1.Member-1] ip route-static 3.0.0.0 8 10.0.0.1
# Configure member switch 2.
[HUAWEI_2.Member-2] ip route-static 3.0.0.0 8 10.0.0.1
# Configure member switch 3.
[HUAWEI_3.Member-3] ip route-static 3.0.0.0 8 10.0.0.1
NOTE
Multiple member switches can be configured simultaneously through incremental configuration. For
configuration details, see Example for Configuring the Incremental Configuration Function for an
HGMP Cluster.
Step 12 Configure the SNMP agent function on member switches.
# Configure member switch 1.
[HUAWEI_1.Member-1] snmp-agent target-host trap address udp-domain 3.0.0.1 params
securityname cluster
# Configure member switch 2.
[HUAWEI_2.Member-2] snmp-agent target-host trap address udp-domain 3.0.0.1 params
securityname cluster
# Configure member switch 3.
[HUAWEI_3.Member-3] snmp-agent target-host trap address udp-domain 3.0.0.1 params
securityname cluster
NOTE
Multiple member switches can be configured simultaneously through incremental configuration. For
configuration details, see Example for Configuring the Incremental Configuration Function for an
HGMP Cluster.
Step 13 Verify the configuration.
After the previous configuration, run the display current-configuration filter snmp command,
you can find that the SNMP agent is enabled and the UDP domain of the administrator switch
is 3.0.0.1, the address of the SNMP host. Take the displayed information about the administrator
switch and Member-3 as examples.
Quidway S9300 Terabit Routing Switch
Configuration Guide - Network Management 8 HGMP Configuration
Issue 03 (2010-09-20) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
8-81
