8.2.1 Test Results Screen Values
The following section describes the fields and buttons on the Test Results screen.
Item Description
Mold Diagnostics Opens the Mold Diagnostics screen.
Rewire Automatically reassigns all the sensors to their proper location based on
the results of the test.
Cross-Talk Opens the Cross-Talk screen.
Temperature Graphs Opens the Temperature Graphs screen.
Start Time Time the most recently conducted test was started.
Elapsed Time Duration of the most recently completed test.
Item Description
Zone Zone number
Name Zone name
Sen. Indicates the number of the sensor being used for that zone.
Fuses The fuses test will determine whether the fuse for that zone is operating
correctly. Fuse values are displayed as follows:
• Question Mark: indicates the fuse for the zone was not tested.
• Check Mark: indicates the fuse for the zone passed the test.
• X: indicates the fuse for the zone failed the test.
T/C The thermocouple test will determine whether the thermocouple for
that zone is operating correctly. Thermocouple values are displayed as
follows:
• Question Mark: indicates the thermocouple for the zone was not
tested.
• Check Mark: indicates the thermocouple for the zone test passed.
• X: indicates the thermocouple for the zone failed the test because it
was reversed or lost.
AMP Current drawn by the heater during the test for each zone.
VAC Line voltage reading taken during the test for each zone.
Watt Power calculated for each zone based on the line voltage and current
readings measured during the test.
OHM Resistance calculated for each zone based on the line voltage and current
readings measured during the test.
