Husky Altanium Delta3 - Servicing the Altanium System

v 2.3 — September 2015 Altanium Delta3
168 Part Count Base Connector ID
13.3.3 Part Count Base Connector ID
Output / L RED/GRN At standby temperature
Output / M ORG/RED At standby temperature
Output / N BLK/WHT Maximum temperature error
Output / P WHT/BLK Maximum temperature error
Output / R GRN/WHT Communications error
Output / S BLK/RED/WHT Communications error
Output / T BLK/RED Mold cooling enable
Output / U RED/BLK Mold cooling enable
Output / V RED/WHT Process outside limit
Output / W WHT/RED Process outside limit
Output / X GRN/BLK
Output / Y GRN/BLK/WHT
Output / Z WHT/RED/BLK “Run light”
Output / a RED/BLK/WHT “Run light”
Connector/Pin
Field Cable Wire
Color
Signal Function
Connector/Pin
Field Cable Wire
Color
Signal Function
Part Count / A BLK Reset parts counter
Part Count / B WHT Count Parts
Part Count / C RED 24V+
Part Count / D GRN 24V-
Part Count / E BRN Sack full
Part Count / F BLU Sack full
