v 2.3 — September 2015 Altanium Delta3
186 Connecting the Display Module
6. Hold or gently brace the display module. Remove the four screws using the 5/32 inch
hex wrench provided with the controller.
7. Remove the display module from the interface plate.
15.4.2 Connecting the Display Module
To connect the display module:
1. Position the interface plate on the bottom of the display module.
2. Attach the interface plate onto the display module with the four 1/4 inch-20 button
head cap screws.
Figure 15-10 Disconnecting the Delta3 Interface Plate from the Display Module
1. Button Head Cap Screws, Bottom
1
IMPORTANT!
A minimum of 2 people are required to perform this procedure.
