Closing Profile Graph 207
User Guide v 2.3 — September 2015 UltraSync-E, If Equipped
16.5.1 Closing Profile Graph
Use the Closing profile graph to monitor the valve stem close motion profile.
Closing and
Opening Profiles
Description Minimum Maximum Default
Number of Steps Defines the number of profile steps
used during the motion.
1Opening: 2
Closing: 3
1
Position Sets the end position of the motion.
If multiple steps are used, sets the
switch position between steps.
- Close: 0.0mm
Open (Gen1): 10.0 mm
Open (Gen2): 7.4 mm
Maximum
Speed The speed limit of the step. May not
be achieved, depending on travel
distance, acceleration and
deceleration limits.
0.1 mm/s 50 mm/s 50 mm/s
Acceleration The acceleration limit of the step.
May not be achieved, depending
on travel distance of the step.
1 mm/s^2 500 mm/s^2 500 mm/s^2
Deceleration The deceleration limit of the step.
May not be achieved, depending
on travel distance of the step.
1 mm/s^2 500 mm/s^2 500 mm/s^2
Force Limit Maximum force limit applied to all
steps in the motion.
0.0 kN Per tool Tool maximum
Closed Holding
Force
Description Minimum Maximum Default
Apply Closed
Holding Force
If selected, a constant force is
applied in the close direction once
the close position has been
reached.
If deselected, the motor will only
use the minimum force required to
maintain the close position.
-- Enabled
Closed Holding
Force
The constant force applied. 0.0 kN Per tool Tool
recommended
Recommended
Force
The recommended Closed Holding
force for the selected tool.
-- Per tool
