16.3.4 Control Bar Status Indicators
16.3.5 Datalog Values
Use the Datalog Values section to view the values recorded during the last Engaged cycle.
Item Description
IMM E-Stop OK Displays the state of the IMM E-Stop.
IMM Safety Gates
Closed
Indicates the IMM safety gates are closed.
Controller E-Stop OK Displays the state of the UltraSync-E cabinet E-Stop
At Temperature Displays the At Temperature status.
On an UltraSync-E system with integrated hot runner temperature control,
this is the system At Temperature status.
On a stand alone UltraSync-E system, this is the state of the At Temperature
digital input.
Soak Time
Remaining
Indicates the time remaining on the soak timer countdown.
Soak Time Done Soak time countdown is complete.
Servo Drive Enabled Servo drive is powered and enabled.
Calibration OK Indicates UltraSync is calibrated.
Valve Stems Ready
and Engaged
Indicates UltraSync is in Engaged mode with no faults.
Item Description
Active command Displays the command currently being executed by UltraSync.
Plate position Displays the current position of the valve stems.
Active Force Displays the force being applied by the UltraSync motor.
Item Description
Open Duration Elapsed time of the last open motion.
Close Duration Elapsed time of the last close motion.
Open Position Final position of the last open motion.
Close Position Final position of the last close motion.
