Input Base Connector ID 167
User Guide v 2.3 — September 2015 System Options
13.3.1 Input Base Connector ID
13.3.2 Output Base Connector ID
The maximum load on digital outputs is as follows:
110VDC / 0.3A - 33W
30VDC / 2.0A - 60W
120VAC / 0.5A - 60VA
240VAC / 0.25A - 60VA
Connector/Pin
Field Cable Wire
Color
Signal Function
Input / A WHT Remote standby
Input / B WHT/BLK Remote boost
Input / C BLK Remote start
Input / D BLK/WHT Cooling lines not enabled
Input / E BLU Manual boost
Input / F BLU/WHT Remote Stop
Input / G BLU/BLK 24V+
Input / H GRN 24V+
Input / J GRN/BLK 24V-
Input / K GRN/WHT 24V-
Connector/Pin
Field Cable Wire
Color
Signal Function
Output / A GRN Alarm
Output / B ORG/GRN Alarm
Output / C RED Abort (PCM)
Output / D BLU/RED Abort (PCM)
Output / E ORG At temperature
Output / F ORG/BLK At temperature
Output / G BLK Remote standby
Output / H BLU/BLK Remote standby
Output / J WHT At boost temperature
Output / K BLU/WHT At boost temperature
